It is applied to the labeling of round bottle containers with small quantities but many varieties, such as glass bottles, plastic bottles, iron can and so on.
Features: It is applied to the labeling of round bottle containers with small quantities but many varieties, such as glass bottles, plastic bottles, iron can and so on.
Descriptions:
1.Adopt imported electromagnetic clutch with high precision.
2.High class aluminum alloy anodic treatment has long service life.
3.Adopt famous factory electric engine to ensure high load and long period operation.
4.All parts and standardized components are carefully made by adopting stainless steel.
5.With PLC control panel, liquid crystal display has the sense of the times.
Imported label inspection optical coupler can ensure high precision.
Technical parameters:
|
Model |
SL-130 |
|
Electric source voltage |
AC220V/50Hz or 110V/1/60HZ |
|
Power |
150W |
|
Label dimension |
Maximum:120(height)X400(width)mm Minimum:10(height)X30(width)mm |
|
Round bottle dimension |
Maximum:ф125mm Minimum:ф20mm |
|
Label inner core dimension |
Internal diameter:ф75mm, external diameter:ф300mm |
|
External dimension |
580×680×860 |
|
Net weight |
50kg(including code printer) |
|
Gross Weight |
55kg |
|
Packing by Carton |
620×575×870mm 0.31CBM |
